Hygienic single seals
Electropolished single seals in USP Class VI materials with ASME BPE finishes for high-purity pumps.
Pharmaceutical Pump Mechanical Seals
GMP, FDA and USP Class VI-aligned shaft seals for hygienic and high-purity pumps — ASME BPE surface finishes, supplied to spec.
At a glance
- 01USP Class VI elastomers
- 02ASME BPE finish
- 03WFI & high-purity
- 04CIP/SIP
- 05Documented & traceable
We are the manufacturer, not a reseller — so we match the seal to the duty, build it in-house, and supply it at quantities that work for a distributor, an OEM or a maintenance department. Below is how we approach pharmaceutical pump sealing.
USP Class VIelastomers cleared for pharmaceutical contact
ASME BPEsurface finishes that pass a GMP audit
WFI readyseals built for water-for-injection purity
Why pharmaceutical sealing is the strictest duty
Purity is the product — WFI and high-purity media can’t pick up anything from the seal, so materials and finish are documented and traceable.
GMP wants surface finish — ASME BPE electropolished faces and housings that clean completely and pass audit.
CIP and SIP every batch — the seal sees hot WFI, caustic and steam repeatedly without shedding particles.
Aseptic duty may need a double seal with a sterile barrier to protect the product from the outside.
Range
What we supply
From off-the-shelf replacements to fully engineered custom seals — at the quantities your operation actually orders.
Aseptic double seals
Double seals with a sterile barrier fluid for aseptic and contained processing.
Documented & custom
Material certs and traceability, machined to your pump’s BPE standard or from a sample.
Match the seal to the duty
The right face pair and secondary are set by the media and the conditions — not by what a catalogue stocks. The table is a starting point; send us the duty and we confirm it.
| Service | Face pair | Elastomer | Why it matters |
|---|---|---|---|
| WFI / purified water | Silicon carbide / Carbon | USP Class VI EPDM | No leachables into high-purity water |
| CIP / SIP | Silicon carbide / SiC | FKM / USP EPDM | Repeated hot caustic and steam |
| Aseptic process | SiC / SiC, double | USP Class VI | Sterile barrier protects the product |
| High-purity solvents | SiC / SiC | FFKM | Solvent resistance at purity |
Pharmaceutical seals are specified on materials, finish and documentation — USP Class VI elastomers and ASME BPE surface finishes, with certs to match.
Go deeper: Mechanical seals for pharmaceutical pumps: GMP, FDA, USP.
FAQ
Pharmaceutical Pump Seal FAQ
What standards apply to pharma pump seals?
FDA-compliant and USP Class VI materials, ASME BPE surface finishes, and full material traceability for GMP. Aseptic duty may add a sterile-barrier double seal.
Why electropolished / ASME BPE finishes?
A smooth, electropolished surface cleans completely and won’t harbour or shed particles — which is what a GMP audit and a high-purity process require.
Do you provide documentation?
Yes — material certificates and traceability to support qualification, alongside the right USP Class VI elastomers and BPE finishes.
Source Pharmaceutical Pump Seals At Scale
OEM-compatible, custom-machined and private-label seals built in-house to your spec, at low minimums. Send the seal drawing, the seal model or a sample and we’ll quote.
