Power Plant Pump Mechanical Seals
High-temperature and high-pressure seals for boiler-feed, condensate and cooling-water pumps — metal bellows and API 682, supplied to spec.
Metal bellows · API 682 · High T & P · Plan 23 / 53 · Boiler-feed, condensate, CW pumps
We are the manufacturer, not a reseller — so we match the seal to the duty, build it in-house, and supply it at quantities that work for a distributor, an OEM or a maintenance department. Below is how we approach power plant pump sealing.
Metal bellows
no elastomer to fail at boiler-feed heat
API 682
engineered to the process-seal standard
High T & P
seals for the hardest pump duty on site
Why power-plant pumps need the toughest seals
- Boiler-feed heat and pressure push past what an elastomer secondary can take — metal bellows seals remove the rubber from the hot zone.
- Flashing and thermal distortion open the faces; a cooled flush (Plan 23) keeps them stable.
- Cooling-water intakes carry silt and debris that abrade soft faces — silicon carbide pays off.
- Availability is everything — a seal failure on a boiler-feed pump is lost generation, so the seal is specified for margin.
What we supply
From off-the-shelf replacements to fully engineered custom seals — at the quantities your operation actually orders.
Metal bellows seals
Elastomer-free bellows seals in SiC/SiC for boiler-feed and high-temperature duty.
API 682 cartridge seals
Single and double cartridge seals to API 682 with Plan 23/53 piping for hot, high-pressure pumps.
Custom & OEM-compatible
Machined to your pump’s dimensions or reverse-engineered for legacy boiler-feed and CW pumps.
Match the seal to the duty
The right face pair and secondary are set by the media and the conditions — not by what a catalogue stocks. The table is a starting point; send us the duty and we confirm it.
| Pump duty | Face pair | Secondary | Flush |
|---|---|---|---|
| Boiler feed (high T/P) | SiC / SiC bellows | Flexible graphite | Plan 23 cooled |
| Condensate | SiC / Carbon | FKM | Plan 11 / 23 |
| Cooling water | SiC / Carbon | EPDM | Plan 11 |
| CW intake (silty) | SiC / SiC | FKM | Plan 32 clean barrier |
Power Plant Pump Seal FAQ
Why metal bellows seals for boiler feed?
At boiler-feed temperatures an elastomer secondary hardens and fails. A metal bellows seal replaces the rubber with a welded metal bellows, so there’s nothing to cook in the hot zone.
What flush plan for high-temperature pumps?
A cooled recirculation flush — API Plan 23 — keeps the seal faces below the flashing point and stable. Cooling-water intakes with silt often add a Plan 32 clean barrier.
Do you build to API 682?
Yes — metal bellows and cartridge seals to API 682 with the matching piping plans, for boiler-feed, condensate and cooling-water pumps.
Source Power Plant Pump Seals At Scale
OEM-compatible, custom-machined and private-label seals built in-house to your spec, at low minimums. Send a pump model, a duty sheet or a sample and we’ll quote.
